40G QSFP+ Single Mode Transceiver

40G QSFP+ Single Mode Transceiver

  • 40G QSFP+ Single Mode Transceiver

Designed for 40G Ethernet and OTU3 links over single-mode fibers, the Sintai 40G QSFP+ single-mode optical transceivers use CWDM wavelengths (1271nm, 1291nm, 1311nm, and 1331nm) and support transmission distance up to 40km.

40G QSFP+ Single Mode Transceiver PDF Download Contact Us

40G QSFP+ Single Mode Transceiver Feature

  • Adopt QSFP+ hot-swappable encapsulation with LC interface for single mode.

  • 4 x 10Gb/s laser is adopted.

  • Support an overall rate of 39.8 Gb/s~44.6 Gb/s.

  • Support network applications such as 40G Ethernet and OTU3.

  • Single-mode optical fiber supports a transmission distance of up to 40km.

  • Built-in DDM (digital diagnostic monitoring function).

  • Working temperature: 0°C ~ +70°C.

  • Comply with RoHS standards.


40G QSFP+ Single Mode Transceiver Overview

The 40G QSFP+ optical communication module launched by Sintai Communication Co., Ltd. is specifically designed for 40G Ethernet and 40G OTN applications.


The module conforms to the QSFP+ MSA standard and IEEE 802.3ba standard ad supports a maximum rate of 44.6Gb/s, with digital diagnostic capabilities.

The product contains two kinds' modules: single-mode module and multimode module.


The single-mode module is equipped with MUX/DEMUX devices, and it uses wavelength division multiplexing technology to multiplex the 4 x 10Gb/s CWDM channel on a single optical fiber, with the longest transmission distance of up to 40km. It's widely used in environments such as large data centers, campus networks, metro networks, etc.


40G QSFP+ Single Mode Transceiver Specification

Model

ST-QSQL-31

ST-QSQE-31

Operating wavelength (nm)

1271, 1291, 1311, 1331

1271, 1291, 1311, 1331

Operating rate (Gb/s)

4x11.2

4x11.2

Optical power range of single-channel transmitting (dBm)

-2.3~+2.3

-2.7~+4.5

Optical power range of single-channel receiving (dBm)

-13.7~+2.3

-21.2~-4.5

Power range of total transmission (dBm)

≤+8.3

≤+10.5

Power range of total receipt (dBm)

-7.7~+8.3

-15.2~+1.5

Transmission distance (km)

10 (SMF)

40 (SMF)

Extinction ratio (dB)

4.5

5.5

Working temperature range (°C)

0~+70

0~+70
