4CH DWDM Mux Demux

4CH DWDM Mux Demux

  • 4CH DWDM Mux Demux (1).jpg
  • 4CH DWDM Mux Demux
  • 4CH DWDM Mux Demux (1).jpg
  • 4CH DWDM Mux Demux

DWDM Mux Demux is usually used for long-haul transmission where wavelengths are packed tightly together over the C-band, up to 48 wavelengths in 100GHz grid(0.8nm) and 96 wavelengths in 50GHz grid(0.4nm). Its protocol is transparent and suits applications including 10/1G Ethernet, SDH/SONET, 16/8/4/2/1G Fibre Channel, FTTX, and CATV.


Our DWDM Mux Demux are modular, saleable, and are perfectly suited to transport PDH, SDH / SONET, ETHERNET services over WDM, CWDM, and DWDM in optical metro edge and access networks.


4CH DWDM Mux Demux PDF Download Contact Us

4CH DWDM Mux Demux Features

  • Low Optical Insertion Loss

  • Mux/Demux Four/Eight wavelengths

  • SC connectors for interfacing

  • Reliable passive WDM optical technology

  • Scales easily for ring networks

  • Low-profile modular design

  • Fits in 1RU 19" rack mount chassis

  • Compliance with ROHS


4CH DWDM Mux Demux Specification

Parameter

Unit

MUX/DEMUX

Channel Number

CH

4

Operating Wavelength

nm

1525~1565 Optional

Center Wavelength@λc

nm

C Band, ITU Grid

Channel Spacing

nm

0.8nm(100GHz)

Channel Insertion Loss

dB

≤1.5

Pass-band Bandwidth

nm

ITU±0.11

Channel Ripple

dB

≤0.5

Adjacent Channel Isolation

dB

≥30

Non-Adjacent Channel Isolation

dB

≥35

Return Loss

dB

≥50

Directivity

dB

≥50

PDL

dB

≤0.15

PMD

ps

≤0.1

Power Handling

mW

≤500

Operating Temperature

°C

-10~+70

Storage Temperature

°C

-40 ~+85

Fiber Type

-

Corning SMF-28e Ultra

Package Size

mm

100x80x10
