10G SFP+ BiDi Transceiver

10G SFP+ BiDi Transceiver

  • 10G SFP+ BiDi Transceiver

Designed for Ethernet, Fiber Channel, SDH, SONET, CPRI, or OTN links over simplex single-mode fiber, the Sintai 10G SFP+ BiDi optical transceivers use 1270nm and 1330nm wavelengths and support transmission distance up to 40km and are used in pairs.

10G SFP+ BiDi Transceiver PDF Download Contact Us

10G SFP+ BiDi Transceiver Feature

  • Adopt SFP+ hot-swappable encapsulation with LC interface.

  • Support an overall rate of 1.06Gb/s~11.3Gb/s with service compatibility.

  • Support single-fiber bidirectional transmission.

  • Suitable for networks such as Ethernet/ FC/ SDH/ SONET/ CPRI/ OTN.

  • Single-mode optical fiber supports a transmission distance of up to 40km in single-fiber bidirectional transmission system.

  • Built-in DDM (digital diagnostic monitoring function).

  • Working temperature: 0°C ~ +70°C.

  • Comply with RoHS standards.


10G SFP+ BiDi Transceiver Overview

The 10G SFP+ optical communication module launched by Sintai Communication Co., Ltd is specifically designed for 10G Ethernet and 1G/2G/4G/8G/10G Fiber Channel applications, and it is compatible with STM-16/64, CPRI 2~8, OTU1/2, and other network applications.


The module conforms to the MSA protocol and supports an adaptive rate of 1.06Gbps~11.3Gbps, with the longest transmission distance of 40 km, complying with the RoHS standard, and supporting digital diagnostic function.


The single-fiber bidirectional optical transceiver is used in a single-fiber bidirectional transmission system and should be used in pairs.


10G SFP+ BiDi Transceiver Specification

Model

Description

Transmission distance

Working

wavelength

Transmitting power

Receiving sensitivity

Overload power

(km)

(nm)

(dBm)

(dBm)

(dBm)

ST-SBXL-23

SFP+, 10G, single fiber A bidirectional

10

1270T/1330R

-6~+0.5

≤-14

0.5

ST-SBXL-32

SFP+, 10G, single fiber B bidirectional

10

1330T/1270R

-6~+0.5

≤-14

0.5

ST-SBXE-23

SFP+, 10G, single fiber A bidirectional

40

1270T/1330R

0~+5

≤-15

0.5

ST-SBXE-32

SFP+, 10G, single fiber B bidirectional

40

1330T/1270R

0~+5

≤-15

0.5
