25G SFP28 Multimode Transceiver

25G SFP28 Multimode Transceiver

  • 25G SFP28 Multimode Transceiver

Designed for 25G Ethernet 25GBASE-SR and CPRI/eCPRI links over duplex multimode fibers, the 25G SFP28 SR industrial optical module supports transmission distance up to 100m using 850nm wavelengths.

25G SFP28 Multimode Transceiver PDF Download Contact Us

25G SFP28 Multimode Transceiver Feature

  • Hot-pluggable SFP28 form factor

  • Compliant with SFP MSA standard

  • Compliant with IEEE 802.3by 25GBASE-SR standard

  • Compliant with CPRI and eCPRI specifications

  • Single-channel full-duplex transceiver module

  • Supports 25Gb/s data rate

  • 850nm VCSEL

  • PIN photo-detector

  • 1W maximum power dissipation

  • Maximum link length of 70m on OM3 MMF or 100m on OM4 MMF

  • Dual LC receptacles

  • Built-in digital diagnostic functions

  • Industrial operating case temperature range: -40 to 85°C

  • Single 3.3V power supply

  • RoHS-6 compliant (lead-free)


25G SFP28 Multimode Transceiver Specification

Package

Part Number

Data Rate

Reach

(km)

Wavelength

(nm)

TX output

(dBm)

RX sensitivity

(dBm)

RX overload

(dBm)

Interface

SFP28 SR

ST-SMVS-85

25G

0.1

850

-8.4~2.4

-10.3

3

LC
