Designed for 25G Ethernet and CPRI/eCPRI links over duplex single-mode fibers, the 25G SFP28 CWDM industrial optical modules support transmission distance up to 10km using 1270nm, 1290nm, 1310nm, or 1330nm CWDM wavelengths.
PDF Download
Contact Us
Hot-pluggable SFP28 form factor
Compliant with SFP MSA standard
Compliant with CPRI and eCPRI specifications
Single-channel full-duplex transceiver module
Supports 25Gb/s data rate
1.5W maximum power dissipation
Maximum link length of 10km on SMF
Dual LC receptacles
Built-in digital diagnostic functions
Industrial operating case temperature range: -40 to 85°C
Single 3.3V power supply
RoHS-6 compliant (lead-free)
25GE LR
CPRI Option 10
Package | Part Number | Data Rate | Reach (km) | Wavelength (nm) | TX output (dBm) | RX sensitivity (dBm) | RX overload (dBm) | Interface |
SFP28 CWDM | ST-SCVL-XX | 25G | 10 | CWDM | 1～7 | -11.3 | 2 | LC |
